Three-axle six-shaft folding gooseneck low-bed semi-trailer

Manufactured in Shandong, China, the LUYI 3-Line 6-Axle Folding Gooseneck Lowbed Semi-Trailer is a professional semi-trailer specially designed for heavy-duty equipment transportation.

The trailer offers two material options: carbon steel and aluminum, balancing structural strength and lightweight needs. With a maximum payload of 80 tons, it can efficiently handle the transportation of heavy-duty equipment. It adopts a 6-axle design, equipped with well-known brand axles (Fuwa or BPW), and matched with tires in multiple specifications (12R22.5, 12.00R20, 11R22.5). Mechanical or air suspension systems are optional to ensure driving stability and cargo safety.

In terms of details, it is fitted with standard 28-ton landing gear and provides JOST king pins in two options: 2" (50mm) or 3.5" (90mm) to adapt to different tractors. The body color is customizable by customers, and the folding gooseneck design further enhances transportation flexibility. It is an ideal choice for heavy-duty equipment transfer in engineering, mining and other fields.

Max Payload：80 ton

Suspension：Mechanical Suspension Air Suspension

Tire：12R22.5/12.00R20/11R22.5

King pin：2"(50mm)or3.5"(90mm) JOST

Landing Gear：Standard 28Ton

Function：Transport Heavy Duty Equipment

Axle Brand：Fuwa BPW Brand

Color：Customers Optional

FAQ

1. What are your advantages?

We have 23 years of export work experience, and our products have been exported to more than 60 countries and regions including Africa, the Middle East, Southeast Asia, South America, etc.

We have a professional after-sales service technical team that can solve your problems in time

2. What payment methods do you accept?

L/C and T/T

3. We want tubeless trucks, is that ok?

Yes, both radial tires and tubeless tires are optional.

4. What logistics methods can you use for transportation?

We can use various transportation tools to transport construction machinery.

(1) Our main mode of transportation is that the machine will be shipped by container or ro-ro/bulk.

(2) For China's inland neighboring countries, we can ship the machine by road or rail.

(3) For urgently needed spare parts, we can ship by DHL, TNT, UPS or FEDEX.

5. In addition, what other products does your factory produce?

Our factory not only produces tractors, but also dump trucks, sprinkler trucks, truck cranes, mixer trucks, dump trailers,tank trailers, low-bed trailers, dust removal trailers, etc.Our factory is large in scale and can customize different products according to different customer requireme
